5 to 20 amp ratings.
Provides circuit protection and power switching in a single unit.
Available with optional indicator lamp.
Snaps into the same cutout as many common power switches.
Various color, marking and termination options.
Rated voltage AC 125/250V DC 50V
Rated current 5~20 A
Interrupt Capacity 1000A 250V（UL1077）
Dielectric strength AC 1500V (1min)
Insulation resistance ≧100 MΩ, 500VDC
Resettable Overload Capacity Ten times rated current
Switch Endurance Cycling Over 6,000 operations
at rating current
Weight: Approx 9.5g
Rated current 5~20 A
Interrupt Capacity 1000A 250V（UL1077）
Dielectric strength AC 1500V (1min)
Insulation resistance ≧100 MΩ, 500VDC
Resettable Overload Capacity Ten times rated current
Switch Endurance Cycling Over 6,000 operations
at rating current
Weight: Approx 9.5g
